Customize Your Osburn Inspire Wood Stove

Customizing a product with us is simple and flexible. Following these steps, you can easily customize a product to meet your needs.


Instructions:
1. Choose a base product model.
2. Explore available options.
3. Select choices to view the total price.
4. Add the customized product to the cart and checkout.

Status: In Stock

US$3,049.00
Stove

Osburn Inspire 2000 Wood Stove (US$3,049.00)
Faceplate (Required)

Osburn Decorative Side Panel Kit, 2000, Inspire 2000 (US$200.00)
Base (Required)

Osburn Black Steel Base Kit, Inspire 2000 (US$550.00)
Osburn Minimalist Base Kit, Inspire 2000 (US$350.00)
Optional

Osburn Fresh Air Intake Register W/ Airtight Damper 5" (US$250.00)
Osburn Part Quick Connect Thermodisc Kit (US$75.00)
Osburn Blower Assembly W/Varible Speed Control,Inspire 2000 (US$300.00)
Main Item Price US$ 0.00
Optional Item Price US$ 0.00
Price for this Configuration US$ 0.00

Description

Description

Introducing the Osburn Inspire Wood Stove, a perfect blend of style, efficiency, and innovation. Designed to elevate your heating experience, this wood stove is crafted with meticulous attention to detail and built to the highest standards. Let's explore its features and discover the ideal size application for this remarkable product.

The Osburn Inspire Wood Stove is an exceptional heating solution that combines contemporary design with advanced technology. With its sleek and modern appearance, it adds a touch of elegance to any living space. The large glass window offers a mesmerizing view of the dancing flames, creating a captivating focal point that enhances the ambiance of your home.

Equipped with powerful heating capabilities, the Inspire Wood Stove can efficiently heat medium to large-sized areas. With a recommended heating area of 500 - 2,100 square feet, it is well-suited for spacious living rooms, open-concept spaces, cabins, and even small homes. Experience the cozy warmth it provides on cold winter nights and enjoy the comfort it brings throughout the heating season.

The Inspire Wood Stove is designed for ease of use and optimal performance. It features user-friendly controls that allow you to adjust the heat output and maintain the desired temperature effortlessly. The stove's advanced combustion system ensures efficient burning and reduced emissions, making it both eco-friendly and cost-effective.

In terms of durability, the Inspire Wood Stove is built to last. It is constructed with high-quality materials, offering excellent heat retention and longevity. The stove's firebox is designed to accommodate logs of up to 16 inches, providing an extended burn time and reducing the need for frequent reloading.

Safety is a top priority with the Inspire Wood Stove. It is equipped with safety features such as a robust door latch and an efficient airwash system that keeps the glass window clean, allowing for an unobstructed view of the flames while ensuring safe operation.

Upgrade your heating experience with the Osburn Inspire Wood Stove and enjoy the perfect combination of style and efficiency. Whether you're looking to add a statement piece to your living room or seeking a reliable heating solution for your home, this wood stove is the ideal choice. Embrace the warmth, comfort, and sophistication it brings to your living space and create a cozy haven for yourself and your loved ones.

A Tax Credit is available for this product!

Features

Features

  • Fuel type: Dry cordwood
  • Recommended heating area (sq. ft.): 500 - 2,100
  • Overall firebox volume: 2.4
  • EPA loading volume (cu. ft.): 2.02
  • Maximum burn time: 8 h
  • Maximum heat output (dry cordwood): 75,000 BTU/h (22.0 kW)
  • Overall heat output rate (min. to max.): 14,800 BTU/h (4.34 kW) to 28,600 BTU/h (8.38 kW)
  • Average overall efficiency (EPA cribs/Douglas fir): N.A. (HHV) N.A. (LHV)
  • Average overall efficiency (dry cordwood): 69% (HHV) 74% (LHV)
  • Optimum efficiency: 77%
  • Average particulate emissions rate: 1.54 g/h
  • Average CO: 89.4 g/h

Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

(Average Overall Efficieny) As measured per CSA B415.1-10 stack loss method.

(HHV) Higher Heating Value of the fuel.

(LHV) Lower Heating Value of the fuel.

Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

Optimum overall efficiency at a specific burn rate (LHV).

 This appliance is officially tested and certified by an independent agency.



Specifications

Specifications

Combustion technology: Non-catalytic
High-efficiency certified appliance: Yes, EPA 2020 approved
Maximum log length: 20"
Log positioning: Over width
Chimney diameter: 6"
Flue outlet diameter: 6"
Type of chimney: CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet): 12'
Baffle type: C-Cast
Approved for an alcove installation: Yes
Approved for a mobile home installation: Yes, with fresh air intake
Shipping Weight: 537 lb (244 kg)
Door type: Single, glass with steel frame
Glass type: Ceramic glass
Glass surface – dimensions (Width X Height): 20 1/4" X 9 1/2"
Glass air-wash system: Yes
Overall dimension (Height): 36 9/16"
Overall dimension (Width): 27 7/8"
Overall dimension (Depth): 24 15/16"
Door opening – dimension (Height): 8 3/8"
Door opening - dimension (Width): 20"
Firebox – dimension (Height): 11 15/16"
Firebox – dimension (Width): 21 1/4"
Firebox – dimension (Depth): 17 11/16"
Firebox lined with refractory bricks for better heat distribution: Yes
Stainless-steel secondary-air system improving gas combustion: Yes
Model: Pedestal
Steel thickness – body: 3/16"
Steel thickness – top: 5/16"
Easy-to-access ash drawer: Yes
USA standard (emissions): EPA Method 28
Canadian Standard (emissions): CSA B415.1-10
USA standard (safety): UL 1482, UL 737
Canadian standard (safety): ULC S627
Tested and listed as per applicable standards: By an accredited laboratory (CAN/USA)
Warranty: Limited lifetime



Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)

                                                                                    Canada                      USA

  Single wall pipe Double wall pipe

Single wall pipe

Double wall pipe
Clearance – back wall 14 ½" 6" 11" 6"
Clearance - corner 10" 7" 10" 7"
Clearance – side wall 17" 17" 16" 16"
Clearance – top (measured from the platform on which the appliance is installed)** 84" 84" 84" 84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
