Osburn 950 Wood Stove

OB00950

Status: In Stock

US$1,849.00

Description

Description

*Pricing reflects additional freight costs to Alaska.

The Osburn 950 Wood Stove is specifically designed to meet the heating needs of small to medium-sized applications. Its ample size and powerful performance make it an ideal choice for heating spacious living rooms, family rooms, open-concept areas, cabins, and even small offices or workshops. Recommended heating area 250 - 1,200 sq. ft.

With the 950 Wood Stove, you can create a warm and inviting atmosphere, perfect for relaxing evenings or gatherings with family and friends. Its stylish design adds a touch of elegance to any space, complementing various interior styles and decor.

Equipped with advanced features, the Osburn 950 Wood Stove ensures optimal heat distribution throughout your space. The stove's innovative combustion technology maximizes efficiency, effectively converting wood fuel into cozy warmth. This not only keeps your space comfortably heated but also helps reduce fuel consumption, making it an environmentally friendly choice.

The sturdy construction of the 950 Wood Stove guarantees long-lasting durability, allowing you to enjoy its reliable performance for years to come. Its robust build and high-quality materials ensure it can withstand the demands of regular use and provide consistent heat output.

Whether you're looking to heat a large living room where everyone can gather comfortably or a cozy cabin where you can escape the chill, the Osburn 950 Wood Stove offers the perfect balance of style, reliability, and efficiency. Upgrade your heating system with the Osburn 950 Wood Stove and transform your space into a warm and welcoming sanctuary.

A Tax Credit is available for this product!

Features

Features

  • Fuel type: Dry cordwood
  • Recommended heating area (sq.ft.): 250-1,200
  • Firebox volume (cu. ft.): 1.7
  • Maximum burn time: 5 h
  • Maximum heat output (dry cordwood): 45,000 BTU/h (13.19 kW)
  • Overall heat output rate (min. to max.): 12,124 BTU/h (3.55 kW) to 22,700 BTU/h (7.83 kW)
  • Average overall efficiency (dry cordwood): 74% (HHV) 79% (LHV)
  • Optimum efficiency: 80%
  • Average particulate emissions rate: 1.8 g/h
  • Average CO: 74 g/h

Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

 Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³. Other performances are based on a fuel load prescribed by the standard. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

As measured per CSA B415.1-10 stack loss method.

Higher Heating Value of the fuel.

Lower Heating Value of the fuel.

Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

Optimum overall efficiency at a specific burn rate (LHV).

This appliance is officially tested and certified by an independent agency.



Specifications

Specifications

Combustion technology Non-catalytic
High-efficiency EPA certified appliance Yes, EPA 2020 approved
Maximum log length 17"
Log positioning Loading over depth
Chimney diameter 6"
Flue outlet diameter 6"
Type of chimney CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet) 15'
Baffle type High quality vermiculite
Approved for an alcove installation Yes
Approved for a mobile home installation Yes, with fresh air intake
Shipping Weight 280 lb
Door type Single, glass with cast iron frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 10 1/4" x 8 7/8"
Glass air-wash system Yes
Overall dimension (Height) 28 7/8"
Overall dimension (Width) 20 1/4"
Overall dimension (Depth) 27 7/8"
Door opening – dimension (Height) 7 5/8"
Door opening - dimension (Width) 12"
Firebox – dimension (Height) 11 3/4"
Firebox – dimension (Width) 14 1/4"
Firebox – dimension (Depth) 19 1/8"
Firebox lined with refractory bricks for better heat distribution Yes
Stainless-steel secondary-air system improving gas combustion Yes
Steel thickness – body 3/16"
Steel thickness – top 5/16"
USA standard (emissions) EPA
Canadian Standard (emissions) CSA B415.1-10
USA standard (safety) UL 1482, UL 737
Canadian standard (safety) ULC S627
Tested and listed as per applicable standards By an accredited laboratory (CAN/USA)
Warranty Limited lifetime



Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)

                                                                                     Canada                    USA

  Single wall pipe Double wall pipe Single wall pipe Double wall pipe
Clearance – back wall 14 1/2" 6" 13" 6"
Clearance - corner 12" 12" 12" 12"
Clearance – side wall 10" 10" 10" 10"
Clearance – top (measured from the platform on which the appliance is installed)** 84" 84" 84" 84"
Clearance – minimum floor protection in front of the appliance 18"   16"

*The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
